Technical data

Unit structure 1.75″×1（Tweeter） 10″×1（Bass）

Rated power    350W

Peak power      700W

Rated impedance    8Ω

Sensitivity         98dB（1W/1M）

Max sound SPL         126dB

Frequency response         45Hz-20KHz(±3dB)

Physical data

Box structure  Positive trapezoidal cabinet

Box material    18mm multilayer birch splint

Finish        Water-based piano lacquer

Metal treatment     High temperature paint handling

Face mask Material Steel net+Spongedustnetwork/netcloth

Lifting way        19×M8 suspension（sings

Dimensions (H x W x D): 500 mm x 360 mm x 310 mm

Weight    21KG

Product Highlights：

Two way 10 inch low-frequency drive unit and 1.7-inch high-frequency, all using customized DIF units from the UK.
Small size, high sensitivity, high sound pressure, clear language, can meet different sound amplification venues.  
Advanced frequency divider design ensures reliable operation of the driver
M8 multi-point hanging method is convenient for lifting
Widely used in mass market KTV, multifunctional halls, teaching, auditoriums, various high-end conference rooms and other sound reinforcement venues
